Description

Core technology:

1. Automatic detection of more posts and less sheets, non-stop rejection, staggered book collection
2. The bearing adopts embedded installation, integrated with the frame, low vibration and low noise
3. PLC control system, stable and reliable operation
4. Host frequency conversion, stepless speed change, touch screen operation is easier to operate
5. Single rotary wheel, Easy and fast disassembly and maintenance
6. Double diameter drum type is adopted, which has fast speed and higher stability

Technical parameters

Maximum page size (mm)	290x380 290*380
Minimum page size (mm)	115x158
Maximum mechanical speed (r/h)	6000
Host power	5kw
Machine weight	600kg/group
Overall dimension(mm)	1524x1000x1800
The maximum page size is optional, and the number of page stations is optional

Electrical configuration

NO	Accessory name	Name	remark
1	PLC	Delta	Machine
2	Frequency converters	Delta	Machine
3	Touch touch LCD display	Delta	Machine
4	Vacuum air pump	Orion(Japan)	Machine
5	bearing	NSK(Japan)	Machine
6	Solenoid valve	SMC(Japan)	Machine
7	Air cylinder	SMC(Japan)	Machine
8	Power switch	Schneider (France)	Machine
9	Photoelectric switch	Panasonic	Machine
10	Proximity switch	Omron	Machine
11	AC contactor	Schneider (France)	Machine
12	Intermediate relays	Schneider (France)	Machine
